1. Product Overview: Core Cooling module for Centrifugal Compressors

The Centac Cooler CH₄ is a purpose-built cooling module designed specifically for Centac series centrifugal air compressors, serving as a critical heat exchange unit in industrial gas compression system setups. Utilizing forced convection heat transfer principles, this equipment effectively transfers heat generated during compression from high-temperature compressed air to cooling media, ensuring stable air temperatures for subsequent compression stages or end-use use cases.

Key Structural modules:

• Tube bundle assembly
• Fin matrix system setup
• Structural support frame
• Powered fan unit

Featuring modular design for compatibility with various Centac compressor models (including 1ACV, C250, C350), this spray-type fixed tube sheet air cooler is configured for demanding industrial use cases in chemical processing, natural gas treatment, and petroleum refining.

Technical Specifications:

2. Technical Features with operational performance Data

2.1 Structural Innovations and Material Advancements

• Tube Bundle Assembly: Bimetal rolled fin tube technology with T2 copper base tube and 0.15mm aluminum fins, achieving 250-300W/(m²·K) heat transfer overall efficiency through high-frequency resistance welding.
• Frame system setup: Q345B carbon steel welded structure with triple-layer anti-corrosion coating (zinc-rich epoxy primer + micaceous iron oxide intermediate + polyurethane topcoat), passing ≥1,000 hours salt spray testing.
• Fan Unit: Backward-curved centrifugal fan with 800-1500mm diameter GFRP blades, featuring 15-100% variable frequency speed control and 5.5-75kW motor power range.

2.2 Thermodynamic operational performance Metrics

3. Industrial use cases and Case Studies

3.1 Typical use case Fields

• Natural Gas Liquefaction: Three-stream spiral wound tube design enables -53°C to -120°C cryogenic heat exchange, improving LNG production overall efficiency by 15%.
• Chemical Processing: PTFE-coated tube bundles withstand corrosive media, extending service life beyond 20 years while reducing annual maintenance costs by 40%.
• Metallurgical Industry: fine-tuned inlet guide vanes and blowback cleaning system setup extend filter replacement cycles from 3 to 12 months in blast furnace use cases.

4. Maintenance Strategy

4.1 Routine Inspection Protocol

• Daily monitoring of coolant ΔT (≤8°C), fan current (≤5% fluctuation), and pressure differential (≤0.02MPa)
• Monthly ultrasonic leak detection with ≤1% allowable leakage rate

4.2 Periodic Maintenance Schedule

5. Technical Summary

The Centac Cooler CH₄ provide exceptional operational performance through:

1. 20% higher heat transfer overall efficiency via corrugated tube and bimetal fin technology
2. 20,000+ hours MTBF through corrosion-resistant modular construction
3. minimized lifecycle costs with intelligent controls and self-cleaning design

As material science and control technologies advance, AirsCooler continues to push boundaries for extreme-condition use cases including cryogenic (-160°C) and highly corrosive (pH≤2) environments.
